Site survey
Before a Sharebox kiosk goes live, we run a Site Survey to make sure everything fits, flows, and functions.
- Done together with our local partners.
- Customer site team gives the final thumbs-up.
- Outcome: clear actions, zero surprises.
It’s not paperwork—it’s boots on the ground. We visit, measure, and stress-test the location so your kiosk install is smooth from day one.
Sharebox Site Survey Application Form
Specifications s32
Kiosk dimensions (HxWxD):
s32 on base frame: 195 x 70 x 30 cm | 76.8 x 27.6 x 11.8″
s32 concrete base: 203 x 100 x 62 cm | 79.7 x 39.4 x 24.2″
Kiosk weight:
s32: 335kg | 738.55 lb
s32 on concrete base: 540kg | 1190.50 lb
No. of lockers:
32
Locker dimensions (HxWxD):
6 x 5,5 x 10 cm I 2.4 x 2.2 x 3.9”
Touch screen display size:
4,3”, optional sizes: 7”
Connectivity:
Cabled Ethernet and L TE-M (2G l 3G l 4G) Ethernet-, Wi-Fi-, LTE Router (optional)
Colours:
Black, Grey, White. Custom colours optional
Operation:
Outdoor or indoor
Operational Temp:
-20°C – +50°C
Power supply:
110-240V 50-60Hz
Power consumption:
150 W
Specifications i16 | i32
Kiosk dimensions (HxWxD):
175 x 65 x 50 cm 168.9 x 25.6 x 2”
Kiosk weight:
i16: 90kg I198.4Ib
i32: 105kg I 231.5Ib
No. of lockers:
16 or 32
Locker dimensions (HxWxD):
6 x 9 x 7 cm I 2 x 3.5 x 2.8”
Frame and lockers in stainless steel
Touch screen display size:
15”
Connectivity:
Cabled Ethernet and L TE-M (2G l 3G l 4G) Ethernet-, Wi-Fi-, LTE Router (optional)
Colours:
Black or white
Operation:
Indoor
Operational Temp:
-20°C – +50°C
Power supply:
100-240VAC
Power consumption:
approx. 10 W
Specifications i16 | i32
- Kiosk dimensions (HxWxD):
175 x 65 x 50 cm 168.9 x 25.6 x 2” - Kiosk weight:
i16: 90kg I198.4Ib
i32: 105kg I 231.5Ib - No. of lockers: 16 or 32
- Locker dimensions (HxWxD):
6 x 9 x 7 cm I 2 x 3.5 x 2.8” - Frame and lockers in stainless steel
- Touch screen display size: 15”
- Connectivity:
Cabled Ethernet and L TE-M (2G l 3G l 4G) Ethernet-, Wi-Fi-, LTE Router (optional) - Colour: Black or White
- Operation: Indoor
- Operational Temp: 0°C – +50°C
- Power supply: 100-240VAC
- Power Consumption: approx. 10 W
i16 | i32 Data Specifications
i32 Installation Guidelines
Specifications m12 | m28
- Kiosk dimensions:
m12 (HxWxD): 80x30x14 cm | 31,5″x11,8″x5,5″
m28 (HxWxD): 80x53x14 cm | 31,5″x20,9″x5,5″ - Kiosk weight:
m12: 25kg | 55.12 lb
m28: 50kg | 110.23 lb - No. of lockers: 12 or 28, expandable to 156
- Locker dimensions (HxWxD):
6 x 8 x 5 cm - Frame and lockers in stainless steel
- Touch screen display size: 4,3”
- Colour: Black or white
- Operation: Outdoor or indoor
- Operational Temp: 0°C – +50°C
- Power supply: 100-240VAC
- Power consumption: approx.10 W
m12 | m28 Data Specifications
m12 | m28 Installation Guidelines
Specifications w64
- Kiosk dimensions (HxWxD):
174x100x15 cm | 68.5 x 39.4 x 5.9″ - Kiosk weight:
130kg | 353 lb - No. of lockers: 64
- Locker dimensions (HxWxD):
6 x 9 x 7 cm | 2 x 3.5 x 2.8” - Frame and lockers in stainless steel
- Touch screen display size: 15”
- Connectivity:
Cabled Ethernet and L TE-M (2G l 3G l 4G) Ethernet-, Wi-Fi-, LTE Router (optional) - Colour: Black
- Operation: Indoor
- Operational Temp: 0°C – +50°C
- Power supply: 100-240VAC
- Power consumption: approx. 20 W
- UPS – Uninterruptible power supply (optional)
w64 Data Specifications
